型號
|
LW-1000
|
LW-1500
|
LW-2000
|
LW-3000
|
LW-4000
|
LW-5000
|
LW-6000
|
|
正常功率
|
1000W
|
1500W
|
2000W
|
3000W
|
4000W
|
5000W
|
6000W
|
|
AC
Input
|
|
相數和波形
|
Single phase & Pure Sine Wave
|
|
電壓
|
110/120/130VAC or 220/230/240VAC
|
|
電壓范圍
|
95-126VAC or 194-253VAC±4%
|
|
Low Line Disconnect
|
85VAC±4% or 184VAC±4%
|
|
Low Line Re-connect
|
95VAC±4% or 194VAC±4%
|
|
High Line Disconnect
|
136VAC±4% or 263VAC±4%
|
|
High Line Re-connect
|
126VAC±4% or 253VAC±4%
|
|
頻率
|
50Hz:41-54Hz 60Hz:51-64Hz
|
|
AC
Output
|
|
相數和波形
|
Single phase & Pure Sine Wave (bypass mode sync to
input)
|
|
電壓
|
110/120/130VAC or 220/230/240VAC±10%rms (bypass mode sync to
input)
|
|
功率
|
50Hz±0.3Hz 60Hz±0.3Hz (bypass mode sync to input)
|
|
峰值
|
3
times of rating power
|
|
短路保護
|
Yes, shutdown after 10ms
|
|
功率因數
|
0.9-1.0
|
|
DC
Input
|
|
電池電壓
|
12VDC or 24VDC or 48VDC
|
|
最小的啟動電壓
|
10VDC or 20VDC or 40VDC
|
|
電池低壓報警
|
10.5±0.3vdc or 21±0.6vdc or 42±1.2vdc
|
|
Low DC input Shut-down
|
10±0.3vdc or 20±0.6vdc or 40±1.2vdc
|
|
High DC input Alarm & Fault
|
16±0.3vdc or 32±0.6vdc or 64±1.2vdc
|
|
High DC input Recovery
|
15.5±0.3vdc or 31±0.6vdc or 62±1.2vdc
|
|
MAX 充電電流
|
20A/35A/ 50A/75A/90A(According to the Inverter model)
|
|
System
parameter
|
|
電池功率
|
>85%
|
|
在線功率
|
>96%
|
|
節能
|
Load <=25W (Enabled on “P/S auto” setting of Remote
control)
|
|
報警
|
Sounding when the heat sink’s tem is over 100℃ and shutdown after 30 seconds.
|
|
超載保護
|
110% <LOAD< FONT>
Load>150%, beeps 0.5s every 1s, and Fault after
20s.
|
|
保護
|
low battery、over charging、over temp、over load
|
|
通信
|
RS-232/USB/SNMP(custom-made)
|
|
使用環境
|
0-40℃,0-90%RH(non-condensing)
|
|
噪音
|
<60dB
|
|
重量
|
16kg
|
18kg
|
20kg
|
25kg
|
39kg
|
42kg
|
49kg
|
|
|
|
|
|
|
|
|
|
|
|
|
|
